HELP! Need 09-12 Power Seat Schematics / Wiring Plus Diagrams

[OnSale]

I am swapping my seats tomorrow morning in my 2012 with seats from a 2015 Sport and I have the plug wires diagrams for the 2015 seats but I can not for the life of me find the 2009-2012 wiring schematics for the under seat plugs.

Can someone please share them with me? I have to do this swap tomorrow and I dunno what I’m going to do if I don’t get the wire colors for the plug pins. I have SRS, and pass seat sensors, etc that have to be hooked up when I swap them.


Sent from my iPhone using Tapatalk



[Aaron Blount]



[Aaron Blount]



[maxvanderen]

Does anyone have a wiring diagram for a 2012 and 2015 passenger and driver seat power. My 12 seats are manual and I have power seats from a 15. I know the plugs are different so I’m not sure how to wire everything to make the seats work and avoid an airbag light on the cluster
