BlackBee
Senior Member
So I just received my hids from ddm tuning. Any tips on installing them or guides that I can go off. Because it looks quite confusing
Hid install tips
- Thread starter BlackBee
- Start date
Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.
0212353
Vendor
- Joined
- Jun 29, 2010
- Posts
- 26,460
- Reaction score
- 2,029
- Location
- Florissant, MO
- Ram Year
- 2019 1500 Laramie Sport Crew, 2019 1500 Big Horn Sport Crew & 2016 Charger SRT Hellcat
- Engine
- 2x 5.7L & 6.2L
post a pic of the harness they sent
RompinRam
Senior Member
- Joined
- Oct 24, 2011
- Posts
- 1,501
- Reaction score
- 102
- Location
- Hoffman Estates, IL
- Ram Year
- 2003
- Engine
- 4.7 Magnum
They look super confusing but their plug n play. Put your bulb in first, secure it, then go onto connecting the wiring. They have some photo instructions on their website if you think that'll help you.
OP
OP
BlackBee
Senior Member
There ya go
0212353
Vendor
- Joined
- Jun 29, 2010
- Posts
- 26,460
- Reaction score
- 2,029
- Location
- Florissant, MO
- Ram Year
- 2019 1500 Laramie Sport Crew, 2019 1500 Big Horn Sport Crew & 2016 Charger SRT Hellcat
- Engine
- 2x 5.7L & 6.2L
first...........take twist ties off. LOL - I can't see what all is there.
But it looks like they have a standard harness with some canceller boxes.
But it looks like they have a standard harness with some canceller boxes.
OP
OP
BlackBee
Senior Member
I have 2 of the second picture
0212353
Vendor
- Joined
- Jun 29, 2010
- Posts
- 26,460
- Reaction score
- 2,029
- Location
- Florissant, MO
- Ram Year
- 2019 1500 Laramie Sport Crew, 2019 1500 Big Horn Sport Crew & 2016 Charger SRT Hellcat
- Engine
- 2x 5.7L & 6.2L
why 2?
Fogs don't need it.
As for the heads, red wire goes to battery. the black ones with the rings are grounds. the rest goes to the ballasts or the bulb. Use dielectric grease, make your own grounds and all should be good. If they don't fire up the first time.....check the polarity on the ballasts. I seem to swap one every time I install one. derrrr.
Fogs don't need it.
As for the heads, red wire goes to battery. the black ones with the rings are grounds. the rest goes to the ballasts or the bulb. Use dielectric grease, make your own grounds and all should be good. If they don't fire up the first time.....check the polarity on the ballasts. I seem to swap one every time I install one. derrrr.
