Light Output Shots

[Musclemckeester]

As many of you know I have a problem....I like to be able to see at night.

I've been asked for some light output shots of everything, so enjoy.


My setup is:

5k Projector'd Switchbacks
55w 6k Projector'd heads and fogs
55w 5k HID'd Hella 700s (4x)
35w 5k Reverse HIDs (switched)


I have the projectors run so that when I click the high beam, the cutout drops in both the heads and fogs automatically, untimately creating 4 high beams.

Just heads and fogs:



Heads and fogs ("high beams" on - cutout dropped):



Heads, fogs, cutout dropped, with lightbar lights on:







Reverse light action too:





One more test from a different direction.







And my personal favorite:



Everything is running through this switch now; I love it!





Without even running the lightbar lights, the output from just the heads and fogs with the cutout dropped is just stupid bright. I'm VERY impressed with the projectors and completely sold on them now.



[GhostRam94]

damn thats awesome!!! looks like my heads still need some adjusting cause my output isnt nearly that but then again you have 55w



[4x4Hemi]

Whatcha mean cut out dropped haha sorry I'm not sure what that means??

and how do ya like that auxiliary switch panel? i was thinking about getting one, how do ya wire up to it??



[Musclemckeester]

damn thats awesome!!! looks like my heads still need some adjusting cause my output isnt nearly that but then again you have 55w

Yeah, mine still need to be adjusted a bit too. Can't tell it from the pics, but when I'm driving I can.

Whatcha mean cut out dropped haha sorry I'm not sure what that means??

and how do ya like that auxiliary switch panel? i was thinking about getting one, how do ya wire up to it??

The projector has this cutoff, that's what gives the nice crisp line and keeps the HID bulb from scattering light everywhere. You click the high beams on (which triggers the cutoff to drop), and it scatters the light everywhere.

I love the switch panel. It's a little pricey (about $100), but well worth it IMO. The wiring is a little tricky, but very doable. Basically it's just like wiring a regular 3 pin switch, you just have to put the wires in a different order. Hit me up when you get it and are ready to install it. I'll walk you through it.



[4x4Hemi]

I love the switch panel. It's a little pricey (about $100), but well worth it IMO. The wiring is a little tricky, but very doable. Basically it's just like wiring a regular 3 pin switch, you just have to put the wires in a different order. Hit me up when you get it and are ready to install it. I'll walk you through it.

Sweet! can you just get it from a dealership? I've seen them online and stuff, i probably have to get that little switchboard thing or what ever your supposed to buy with it right? I like the idea of this alotttt better then drilling into my dash



[Musclemckeester]

Sweet! can you just get it from a dealership? I've seen them online and stuff, i probably have to get that little switchboard thing or what ever your supposed to buy with it right? I like the idea of this alotttt better then drilling into my dash

You can probably get it from the dealer with the part number. I picked mine online. Here's what you'd need. The panel and the pigtail connector is all you need. The rest is just basic wiring and a couple standard relays.

Here are the links to the switch panel and harness.

Mopar Part 5164912AC INSTRUMENT PANEL SWITCH

Mopar Part 68057288AA 8 WAY WIRING



[LB3711]

Nice hmm interested on that aux switch too. Better than I wanted to do. Nice and clean looking that way. You need to share.


Sent from my tapatalk equipped AT&T iPhone 5



[4x4Hemi]

You can probably get it from the dealer with the part number. I picked mine online. Here's what you'd need. The panel and the pigtail connector is all you need. The rest is just basic wiring and a couple standard relays.

Awesome thanks, ill check into it today



[RompinRam]

Man Kev, that is a nasty setup haha. I can't wait to get my retro done and light bar setup! Ill be close to the ball park of what you have! Just not hid reverse, only Crees.. Haha



[Musclemckeester]

Nice hmm interested on that aux switch too. Better than I wanted to do. Nice and clean looking that way. You need to share.

Morgan already did it, you can read up on this thread.

http://www.ramforum.com/f51/factory-switch-plate-13814/

I followed his thread.

Awesome thanks, ill check into it today

Cool!

Man Kev, that is a nasty setup haha. I can't wait to get my retro done and light bar setup! Ill be close to the ball park of what you have! Just not hid reverse, only Crees.. Haha

You'll love it. I am surprised how well the HIDs have held up in the reverse lights. Had them in there since April I think? And they are only cheap DDM but have been flawless.



[S2kiHemi]

That's some serious light!



[TexasRammer]

I think i would **** myself if i saw that light in my rearview mirror
Looks sick dude



[RompinRam]

^^ Exactly my plan! I want to have a seperate switch to hit for when I get my train horns. Hit the switch, train horns go off and light bar turns on! Not sure if thats possible or not. But I'm dreaming it up lol.



[Lostnwalmart]

That looks great , I need to upgrade my lights on my truck



[Musclemckeester]

Thanks guys!

I pity the person to ever flash their high beams at me...they'll regret it.

^^ Exactly my plan! I want to have a seperate switch to hit for when I get my train horns. Hit the switch, train horns go off and light bar turns on! Not sure if thats possible or not. But I'm dreaming it up lol.

I'm sure that's very doable.



[bigbadram1500]

Very nice Kevin



[0212353]

spiffy!



[GhostRam94]

Thanks guys!

I pity the person to ever flash their high beams at me...they'll regret it. :

lmao im sure at that height... thats like right in their eyes lol



[Catchin Zs]

Dang that's alot of freaking light. Sick!!



[GhostRam94]

hmm tempted to do hid reverse lol... might sell my crees lmao
