2017 ram 1500 dashboard wiring

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

R

Ram150000

Junior Member
Joined
May 10, 2025
Posts
1
Reaction score
0
Location
South Carolina
Ram Year
2019
Engine
5.7
Hey guys, I recently had to splice in new wiring connectors for my dash airbag and forgot which color goes to which terminal there’s orange brown dark brown and yellow does anybody know or have a picture of where they go?


Attachments

  • IMG_1659.jpeg
    140.8 KB · Views: 6
