Level Tow by Ride Tech install

[Brad360]

Ok gents as I start the planing the install of my rear air ride by Ride Tech. I need some. Ideals and feed back from anyone who has this system. Like where you mounted the leveling switch and compressor? I know it’s not factory stuff but I want to make it look like it belongs. I plan to wire it in the the Fuse bus in the engine bay.



[Loudram]

Looks like a nice system. I just upgraded my springs and I use an Equalizer hitch. That's enough for me.

Can the compressor be exposed to the elements or does it have to be protected? It it can be exposed build a bracket for it and mount it to your frame. If it has to be protected try using a battery box if it's small enough to fit into one and again mount that to the frame with a custom bracket.

As for the switch, do a search for aux light switches and see what others have done. There are tons of options for that.

Posting pics of what the compressor and switch looks like may help with ideas.



[Fieldoc]

I installed level tow bags and used timbergrove auto air setup. The timbergrove allows side to side leveling, one sensor per side and they have a reservoir tank with their system also.



[Ramcharger60]

Am I missing something or is the level tow only a single height sensor? If so shame on ride tech. You have to have individual bag control. I went with Timbergrove due to being mechanical class 8 valves. You can't beat commercial quality

Sent from my SM-N960U1 using Tapatalk
