Harness Backup Camera pin locations

[osprey92]

2017 Ram 1500 Tradesman that came with base radio and reverse image on the rearview mirror. I originally replaced it with an Android system, and last weekend replaced it with another Android unit. I used to have wiring harness pin location diagram but cannot find the diagram. What pin locations/wire colors carry the camera image and power on the harness? I want to splice in and carry reverse camera image into the new unit display. TIA.



[SitKneelBend]

2017 Ram 1500 Tradesman that came with base radio and reverse image on the rearview mirror. I originally replaced it with an Android system, and last weekend replaced it with another Android unit. I used to have wiring harness pin location diagram but cannot find the diagram. What pin locations/wire colors carry the camera image and power on the harness? I want to splice in and carry reverse camera image into the new unit display. TIA.

This site will tell you...search "radio c1"

Mopar Connection Repair Kit

connectorrepairkit.mopar.com



[osprey92]



[HarryS]

It's an industry standard.



[Briautdaddy]

So I am trying to wire factory backup camera from rearview mirror to aftermarket radio I would like help please I don’t know where the camera feed from camera is located in dash and which wires feed the video feed radio only has yellow rca input.



[SitKneelBend]

So I am trying to wire factory backup camera from rearview mirror to aftermarket radio I would like help please I don’t know where the camera feed from camera is located in dash and which wires feed the video feed radio only has yellow rca input.

See this post...

Post in thread 'Express with stock radio replacement' https://www.ramforum.com/threads/express-with-stock-radio-replacement.214861/post-2973575
