Change your rear diff oil if you haven't yet and clean those lockers!

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

thkbaron

Senior Member
Joined
Dec 12, 2019
Posts
1,449
Reaction score
802
Location
Minnesota
Ram Year
2018
Engine
6.4 Hemi
did my rear end tonight. I ended up tossing 3 quarts in the rear end. I've heard of some people going up to four so I'll check it again tomorrow quick while I do the front side. I noticed the bolts had loctite on them and didn't see anything in the beginning about putting some back on. should i back them out one by one and do so or will the 25 be ok with the loctite that was on?


LeesEvoX

Senior Member
Joined
Oct 29, 2017
Posts
1,652
Reaction score
2,213
Location
Houston, TX
Ram Year
2020
Engine
Hemi 6.4l
did my rear end tonight. I ended up tossing 3 quarts in the rear end. I've heard of some people going up to four so I'll check it again tomorrow quick while I do the front side. I noticed the bolts had loctite on them and didn't see anything in the beginning about putting some back on. should i back them out one by one and do so or will the 25 be ok with the loctite that was on?
I didnt put loctite on the bolts when reinstalling. Everything is fine with my truck.

I also just installed a carli front diff guard. So had to take half of the front bolts out again.

All good still

Sent from my SM-G950U using Tapatalk


Gamedog

Senior Member
Joined
Jun 20, 2020
Posts
523
Reaction score
886
Location
State #38
Ram Year
2019 PW
Engine
392 c.i.
Serviced both the front and rear differentials last week with Redline 75-90 I linked previously.

Rear was obviously a lot dirtier than the front, but other than that no major concerns.

Cleaned off all magnets and I did apply loctite to all bolts just to be safe. Gaskets were super solid and put a thin layer of Vaseline on them for ***** and gigs.

Cycled the lockers after 100 or so miles and they engaged super quick.

Glad I did this, thanks all for the input!


liljohn30

Senior Member
Joined
Jun 1, 2012
Posts
127
Reaction score
43
Location
Atlanta
Ram Year
2018
Engine
6.4 hemi
I have a question I have 28K on my power wagon I bought it used from a dealer certified preowned shouldn’t they do this under warranty I still have the original warranty plus I got an extended warranty

OP
OP
Maligator

Maligator

Senior Member
Military
Joined
Jun 30, 2017
Posts
1,162
Reaction score
1,632
Ram Year
2017
Engine
Hem 5.7
I have a question I have 28K on my power wagon I bought it used from a dealer certified preowned shouldn’t they do this under warranty I still have the original warranty plus I got an extended warranty
I'm going to go with a most likely No and even if they did I'm sure they probably didn't clean the magnet off for your locker. I could ve wrong but I think the maintenance interval for fluid changes in the diff is 40k, I did mine about where you're at mileage wise and my rear was filthy I'm glad I did it probably going to do it again at 50k because I'm pretty ****.

Sent from my Pixel 2 using Tapatalk


G. Mcpherson

Senior Member
Joined
Jan 14, 2017
Posts
839
Reaction score
413
Location
Yacolt, Wa.
Ram Year
2023 Ram 2500 CC SB Tradesman
Engine
6.7 Cummins
did my rear end tonight. I ended up tossing 3 quarts in the rear end. I've heard of some people going up to four so I'll check it again tomorrow quick while I do the front side. I noticed the bolts had loctite on them and didn't see anything in the beginning about putting some back on. should i back them out one by one and do so or will the 25 be ok with the loctite that was on?
3.8 qts. Rear.


smurfs_of_war

Senior Member
Joined
Oct 29, 2013
Posts
2,116
Reaction score
1,263
Location
Swift Current, Saskatchewan
Ram Year
2020
Engine
Hemi 6.4
Planned on doing both diffs next week and cleaning the magnets, but now I am confused. I am reading here that the power wagons have a helical LS which doesn't require friction additives, but the manual says I do need them. So which is it? Did the 2020 PW go to a clutch style limited slip?

I realize it won't hurt to add it if I don't need it, but I don't want to spend money I don't have to [emoji16]

Sent from my VOG-L04 using Tapatalk


LeesEvoX

Senior Member
Joined
Oct 29, 2017
Posts
1,652
Reaction score
2,213
Location
Houston, TX
Ram Year
2020
Engine
Hemi 6.4l
Planned on doing both diffs next week and cleaning the magnets, but now I am confused. I am reading here that the power wagons have a helical LS which doesn't require friction additives, but the manual says I do need them. So which is it? Did the 2020 PW go to a clutch style limited slip?

I realize it won't hurt to add it if I don't need it, but I don't want to spend money I don't have to [emoji16]

Sent from my VOG-L04 using Tapatalk
As said above. Just use amsoil. I did, and no problems

Sent from my SM-G950U using Tapatalk


HEMIMANN

Senior Member
Supporting Member
Military
Joined
Dec 7, 2020
Posts
6,798
Reaction score
17,079
Location
Minneapolis, MN
Ram Year
2017 2500 Laramie Crew Cab
Engine
6.4L HEMI
Not sure what they did for Gen V 2500 trucks. Gen IV 2500 trucks (up to 2019) have only AAM 11.5" ring gear and Trac-Rite Torsen all gear "anti-spin" rear axels. Capacity for those is 4.0 qts. avg.

They keep changing around suppliers and designs. I can't keep it all straight. I just know this is what I have.

https://www.dieselhub.com/axle/aam-11.5.html


florida1

Junior Member
Joined
Nov 22, 2020
Posts
1
Reaction score
4
Location
USA
Ram Year
2019
Engine
6.4 Hemi
I just changed the rear fluid out on my 2019 and I'm just shy of 12k miles. As others have seen, I did have some very light shavings. I did install a new gasket, but the original looked great. Torqued everything to 25 and have no leaks.


Gamedog

Senior Member
Joined
Jun 20, 2020
Posts
523
Reaction score
886
Location
State #38
Ram Year
2019 PW
Engine
392 c.i.
Serviced both the front and rear differentials last week with Redline 75-90 I linked previously.

Rear was obviously a lot dirtier than the front, but other than that no major concerns.

Cleaned off all magnets and I did apply loctite to all bolts just to be safe. Gaskets were super solid and put a thin layer of Vaseline on them for ***** and gigs.

Cycled the lockers after 100 or so miles and they engaged super quick.

Glad I did this, thanks all for the input!


Well, my "Axle Unlock" light started blinking again this morning despite the above post. Was 20 degrees and I remember it tends to start blinking when it's below freezing out. Didn't happen yesterday though, and it was about the same temp.

Pretty damn annoying to be honest. I don't want to take it to the dealer as they originally said they could not replicate it the first time I took it in... Very likely it won't be blinking when I take it to them the next time, which would be a waste of my time.


Big Bad Bud

Junior Member
Joined
Mar 17, 2020
Posts
12
Reaction score
31
Location
Dayton, NV
Ram Year
2020
Engine
6.4 Hemi
I did rear diff at 10k miles. It had an unacceptable amount of metal in there. Small shavings and a couple slivers (3/8" and 3/4"). Tells me that FCA just slaps it together ZFG!!


Breaker Alex

Senior Member
Joined
Jul 7, 2019
Posts
258
Reaction score
372
Location
Gatineau, QC, Canada
Ram Year
2019 Power Wagon
Engine
6.4 Hemi
Well, my "Axle Unlock" light started blinking again this morning despite the above post. Was 20 degrees and I remember it tends to start blinking when it's below freezing out. Didn't happen yesterday though, and it was about the same temp.

Pretty damn annoying to be honest. I don't want to take it to the dealer as they originally said they could not replicate it the first time I took it in... Very likely it won't be blinking when I take it to them the next time, which would be a waste of my time.

Mine started flashing more and more around 4000 miles after the oil change.

Now it's everyday. Maybe the cold weather doesn't help, good point mate.

I'll reporte the issue to the dealer just to be on the safe side, if it's worth something.



retired

Votes republican and identifies as a he/him
Joined
Aug 19, 2020
Posts
2,172
Reaction score
2,778
Location
montana
Ram Year
2020
Engine
6.4
this is an old post but figured I would bump it up. It is kind of funny read the owner's manual fill levels lol. why don't they just say to the bottom of the hole? 1/4 below +-1/4 lol.
To check the axle fluid, park the vehicle on a level surface. Take a piece of wire (or zip tie) and make a 90 degree bend two inches from the end of the wire. Insert the wire into the fill plug hole and use it like a dipstick. Remove the wire and measure from the 90 degree bend to the oil level.
For the 2500 (Non-Power Wagon) axles, the fluid level should be 4/5 in ± 1/4 in (20.3 mm ±
6.4 mm) below the fill hole for the rear axle and it shouldbe1/4in±1/4in(6.4mm±6.4mm) below the fill hole on the front axle.
For the 2500 Power Wagon and all 3500 model axles, the fluid level should be 1/4 in ± 1/4 in (6.4 mm ± 6.4 mm) below the fill hole on the 9.25 in front, 11.5 in rear axle, and 12.0 in rear axle.


Scybron

Member
Joined
Feb 14, 2022
Posts
31
Reaction score
31
Location
New Mexico
Ram Year
2022
Engine
da Hemi
just changed rear diff oil to Amsoil on my 22 PW at 800 miles. When I removed fill plug oil was weeping out so manufacture must went +1/4" from the fill line, I filled till it started to weep then let it completly stop weeping before I replaced fill plug. It took around 3.8 qrts to get to the fill hole.

The used oil had a very silvery metallic color, the fill plug has a magnet that was covered in a thick silver metallic paste. The locker magnet had a small amount of same paste, Only saw a few flecks of metal flakes, nothing big.

Only thing I would say, is now I wonder if the wearing in is complete at 800 miles. Probably could of waited till at least 1500 miles before I changed it. Either way I was very suprised how contaminated the oil was.

Rear locker, immediately falls in now after the switch to Amsoil.

Torqued to 25lbs with original gasket, no leaks.


thkbaron

Senior Member
Joined
Dec 12, 2019
Posts
1,449
Reaction score
802
Location
Minnesota
Ram Year
2018
Engine
6.4 Hemi
yeah I might way till 2000 or 3000 miles. I'll see. Getting the first oil change done in a week. Truck will be around 1500 give or take.
